Ngā āhuatanga
Haumaru:
Kua whakamanahia e te maha o nga whakamatautau kino penei i te ara iahiko poto, te wera, te aukati ahi, me etahi atu, kia noho haumaru, kia pono hoki te hua;
Hiko whakaaro whakakotahitanga maha-ahu, tiaki fuse taumata-maha;
Ko te whakauru o roto o nga taputapu PV / ESS / PCS, te mana whakahaere pahi kotahi, te whakapai ake i te pumau o te punaha;
Ko te hoahoa whakamaarama i mua i te oma wera, te whakauru i te kitenga, te aukati ahi, te kitenga hau mura, te aukati auahi me nga mahi whakaora pahū, e mahi tahi ana me te BMS me te EMS ki te whakatutuki i te tinei ahi kua tau ki te taumata PACK;
Pūnaha whakahaere pāmahana atamai, rerekētanga pāmahana pūnaha≤5 ℃, piki te ora o te pākahiko e 12%.
Māmā:
Hoahoa katoa-i-kotahi me te whakaurunga tauira, rūnanga kotahi e hipoki ana i te waahi o te 1.21m² noa;
E tika ana ki nga ahuatanga ahumahi maha me te ngawari ki te hono atu ki te matiti;
Anti-whakauta he hapa iahiko-poto, he watea me te haumaru mo te tiaki;
Te mono me te purei ki te mono rererangi me te roha kaha ngawari ki te uhi i te awhe hiko mai i te 50kW ki te 800kW;
Ko te hangahanga o te wheketere me te kawe whakauru ki te whakaiti i te kawe waka, te whakaurunga me te utu utu ma te 15%.
Maamaa:
Ko te mahi me te tiaki i te kapua mamao, te tautoko i te aroturuki mamao me te rohe;
Rautaki whakataurite atamai me te punaha Al i mua i te whakatupato ki te whakarite kia rite tonu te huringa ora o te pākahiko;
Tautokohia te mahi tiimata pango me te toha hiko pono i roto i te aratau-a-waho/maiti-maiti;
Tautokohia nga momo mahi maha (VPP,matiti-hono,ma-waho) hei whakapai ake i nga moni whiwhi.
Hangarau Tawhā
| Tauira |
YTSmart100 |
PV
Tawhā |
Max.Te mana whakauru |
50KW |
| Ngaohiko whakaoho |
135V |
| PV Max.ngaohiko |
1000Vdc |
| PV ngaohiko whakatau |
620Vdc |
| MPPT awhe ngaohiko whakahaere |
200～850 Vdc |
| MPPT Qty |
4 |
| Te maha o nga hongere whakauru MPPT kotahi |
2 |
| Max.tāuru nāianei |
30A |
| Max.pōtata ia iahiko |
40A |
ESS
Tawhā |
Te mana whakatau |
100KWh |
| Te kaha whakatau |
160Ah |
| Ngaohiko whakatau |
614.4Vdc |
| Awhe ngaohiko pākahiko |
537.6～691.2 Vdc |
| Whakatauhia te utu/tuku o naianei |
80A |
| Max.charge/discharge nāianei |
160A |
AC
Tawhā |
Kua whakatauhia te mana whakaputa |
50KW |
| Max.whakauru mana kitea |
60 KVA |
Matiti-hono
Max.putanga mana kitea |
55 KVA |
| Matiti waho Max.putanga mana kitea |
55 KVA |
| Max.putanga o naianei |
83A |
| Ngaohiko i whakatauhia (whakauru me te whakaputa |
3L/N/PE;220/380V;230/400V;240/415V |
| auau matiti |
50Hz/60Hz |
| THDu |
<3%@whakatauhia te mana me te uta raina |
Tawhā
tōtika |
Max.PV te kaha tahuri |
98.8% |
| te pai o te EU |
98.3% |
ambient
Tawhā |
Te pāmahana whakahaere |
-25 ℃~55 ℃(45 ℃ whakaheke) |
| Te pāmahana rokiroki |
-20℃~45℃ |
| Te haumākū |
5 ~ 95%, karekau he whakamaarama |
| Te teitei |
2000m(2000m te whakaheke) |
| Aratau whakamatao |
Maamaa rangi maatai, maatai powhiriwhiri |
Ētahi
atu tawhā |
Ahu(W*H*D) |
1100*1100*2000mm |
| Taumaha |
1300 kg |
| Kaitiaki whakauru |
IP54 |
| Aratau korero |
CAN,RS485,WiFi/LAN |
